> 상품 > 그리드 인버터에서 >
CE 인증 3kW-110kW IP66 보호

CE 인증 3kW-110kW IP66 보호

네트워크 인버터에 CE 인증

네트워크 인버터 IP66 보호

3kW-110kW 전력 인버터

브랜드 이름:

Greef

인증:

CE

Model Number:

3KW - 110KW

저희와 연락
인용 을 요청 하십시오
제품 세부 정보
전원 출력:
3kw-110kw
MPPT 전압 범위:
50V ~ 1000V
보호:
IP66
출력 전압:
220V-540V
의사소통:
RS485 / 와이파이 / 4G
그리드 모니터링:
최대 작동 고도:
4000m
표시하다:
LCD / LED+APP
강조하다:

네트워크 인버터에 CE 인증

,

네트워크 인버터 IP66 보호

,

3kW-110kW 전력 인버터

지불 및 배송 조건
Minimum Order Quantity
1Set
가격
협상 가능
Packaging Details
Foam+plywooden Case
Delivery Time
25 Working Days
지불 조건
T/T, Western Union, Moneygram
Supply Ability
Supply Ability
제품 설명
CE 인증 3kW-110kW IP66 보호
주요 사양
속성 가치
전력 출력 3kW~110kW
MPPT 전압 범위 50V ~ 1000V
보호 IP66
출력 전압 220V~540V
의사소통 RS485 / WiFi / 4G
네트워크 모니터링
최대 운영 고도 4000m
표시 LCD/LED+APP
CE 인증 3kW-110kW IP66 보호 0 CE 인증 3kW-110kW IP66 보호 1
제품 개요

INVT의 네트워크 연결 인버터 제품은 여러 가지 핵심 기술 이점을 통해 PV 시스템에서 우수한 성능을 보여줍니다.지능형 진단 시스템은 PV 문자열 결함을 정확하게 찾아내고 실시간 파형 기록을 통해 AC 측면 이상을 신속하게 분석합니다.선택적인 아크 파울트 보호 기능 (AFCI) 과 결합하면 탐지에서 반응까지 완전한 안전 메커니즘을 만듭니다.

주요 특징
  • 최대 98.8%의 변환 효율을 가진 넓은 MPPT 전압 범위 설계
  • DC 오버 매칭 기능은 시스템 확장 유연성을 향상시킵니다.
  • 멀티 모드 원격 모니터링 (RS485/WiFi/4G) 은 현장 유지보수를 줄입니다.
  • IP66 보호 등급은 가혹한 야외 환경에 견딜 수 있습니다.
  • DC 역방향 보호, 반섬화 방지 및 급증 보호 등 여러 가지 안전 메커니즘
  • 다중 MPP 추적 기술로 고전력 부품과 호환됩니다.
  • 산업, 상업 및 주거용 용도로 적합합니다.
기술 매개 변수
모델 XG1KTL-S XG2KTL-S XG3KTL-S XG4KTL-S XG5KTL-S
입력 (DC)
최대 입력 전력 1.5kW 3kW 4.5kW 6kW 7.5kW
최대 입력 전압 600V
시작 전압 60V
정형 입력 전압 360V
MPPT 전압 범위 50V ~ 550V
MPPT 당 MPP 추적기 / 문자열 수 1 / 1
최대 MPPT 당 전류 20A
최대 MPPT 당 단회로 전류 26A
출력 (AC)
최대 출력 전류 5A 10A 15A 20A 22.7A
정량 출력 1kW 2kW 3kW 4kW 5kW
최대 출력력 1.1kVA 2.2kVA 3.3kVA 4.4kVA 5kVA
정형 그리드 주파수 50Hz / 60Hz
정렬 전압 220Vac / 230Vac / 240Vac
전력 요인 > 0.99 (0.8 앞선 ~ 0.8 뒤진)
THDi 3% (등급 전력)
MPPT 효율성 99.90%
위의 표는 제품 매개 변수 중 일부만을 보여줍니다. 다른 모델 사양에 대해서는 판매 팀에 문의하십시오.
CE 인증 3kW-110kW IP66 보호 2 CE 인증 3kW-110kW IP66 보호 3 CE 인증 3kW-110kW IP66 보호 4
시스템 솔루션
CE 인증 3kW-110kW IP66 보호 5

우리는 당신의 특정 요구 사항에 맞게 시스템을 사용자 정의 할 수 있습니다. 맞춤형 솔루션을 위해 저희에게 연락하십시오.

CE 인증 3kW-110kW IP66 보호 6 CE 인증 3kW-110kW IP66 보호 7
사용자 정의 옵션
  • 브랜드 이름: Greef
  • 모델 번호: 3KW - 110KW
  • 인증: CE, TUV, SAA
  • 최소 주문량: 1 세트
  • 패키지: 폼 + 접착판 케이스
  • 배송 시간: 25 일
  • 지불 조건: T/T, 웨스턴 유니온, 머니그램
  • 통합 DC 스위치: 예
  • 출력 전압: 220V~540V
자주 묻는 질문
Q: 이 전력 변압기의 브랜드 이름은 무엇입니까?
A: 브랜드 이름은 Greef입니다.
Q: 그리드 인버터에 적용되는 모델 번호 범위는 무엇입니까?
A: 모델 번호는 3KW에서 110KW까지 있습니다.
Q: 이 전력 변압기에는 어떤 인증이 있나요?
A: CE 인증을 받았습니다.
Q: 이 전력 변압기에 대한 패키지 세부 사항은 무엇입니까?
A: 포장에는 폼과 접착판 보호 장치가 포함되어 있습니다.
Q: 이 전력 변압기를 구매하는 데는 어떤 지불 조건이 받아들여집니다?
A: 우리는 T/T, 웨스턴 유니온, 그리고 머니그램 결제를 받아들입니다.
