> 상품 > 영구 자석 발전기 >
최대 120℃ 자석 온도 및 최대 180℃ 권선 온도를 갖는 고효율 영구 자석 발전기 (고부하 작업용)

최대 120℃ 자석 온도 및 최대 180℃ 권선 온도를 갖는 고효율 영구 자석 발전기 (고부하 작업용)

고효율 영구 자석 발전기

최대 120℃ 자석 온도 PMG

최대 180℃ 권선 온도 동기 발전기

브랜드 이름:

Greef

인증:

CE

Model Number:

GDF

저희와 연락
인용 을 요청 하십시오
제품 세부 정보
보호 g:
IP54
고정자 재료:
구리
발전기식:
3 단계 AC 동기 발전기
발전기 쉘 재료:
주철
샤프트 재료:
강철
현재 유형:
AC
냉각방식:
팬 냉각
정격 출력:
0.5-5000KW
강조하다:

고효율 영구 자석 발전기

,

최대 120℃ 자석 온도 PMG

,

최대 180℃ 권선 온도 동기 발전기

지불 및 배송 조건
Minimum Order Quantity
1 Set
가격
협상 가능
Packaging Details
Foam+plywooden Case
Delivery Time
25 Working Days
Payment Terms
T/T
제품 설명
SKF 저 토크 베어링 12-1140V, 고부하 적용 분야
직접 구동 수력 PMG 시스템, 기어박스 제거로 신뢰성 향상
영구 자석 발전기(PMG): 전력 생산 효율성의 도약
A 영구 자석 발전기(PMG)는 기존의 전기적으로 여기된 권선에 의존하는 대신, 강력한 영구 자석을 회전자 위에 사용하여 강력한 자기장을 생성하는 고급 유형의 전기 발전기입니다.
이 혁신적인 설계는 슬립 링과 브러시가 필요 없으므로 다음과 같은 상당한 이점을 제공합니다.
  • 더 높은 효율성: 에너지 손실을 줄여 특히 부분 부하에서 우수한 효율성을 제공합니다.
  • 탁월한 신뢰성: 브러시리스 구조는 최소한의 유지 보수와 더 긴 작동 수명을 보장합니다.
  • 소형 및 경량: 더 높은 전력 밀도를 제공하여 공간 제약적인 응용 분야에 이상적입니다.
  • 우수한 성능: 우수한 전압 조정 및 더 빠른 응답을 제공합니다.
PMGs는 풍력 터빈, 해양 응용 분야, 백업 전원 시스템 및 안정적이고 효율적인 에너지 변환이 필요한 모든 시나리오에 이상적인 전력 솔루션입니다.
제품 매개변수
매개변수
정격 전력 0.5-5000 kW
정격 회전 속도 20-3000 rpm
정격 전압 48-1140 Vac
주파수 60/50 Hz
극 수 24
발전기 유형 3상 AC 동기 발전기
자석 유형 NdFeB
권선 방식 Y
자석 온도 수준 최대 120℃
권선 온도 수준 최대 180℃
효율 >95%
절연 등급 H
절연 저항 100Mohm Min(500Vdc)
등급 분류 IP54
발전기 쉘 재질 주철
권선 재질 100% 구리
샤프트 재질 강철
철심 냉간 압연 규소 강판
베어링 브랜드 SKF
냉각 방식 팬 냉각
무게(N.W /G.W) 132kg /152kg
포장 크기 870*470*570mm
설치 수평
응용 분야
영구 자석 발전기(PMGs)는 높은 효율성, 신뢰성 및 소형 설계를 특징으로 하며, 다양한 현대 산업 분야에서 선호되는 전력 솔루션이 되었습니다.
주요 응용 분야는 다음과 같습니다.
  • 풍력 발전: 현대 직접 구동 및 반직접 구동 풍력 터빈의 핵심 구성 요소로, 특히 가변 속도 작동에서 우수한 효율성을 제공합니다.
  • 신에너지 차량: 전기 및 하이브리드 차량에서 주 구동 모터 또는 보조 발전기로 널리 사용됩니다.
  • 해양 및 해상: 높은 신뢰성과 낮은 유지 보수로 인해 선박 샤프트 발전기 및 주/보조 전력 시스템에 이상적입니다.
  • 백업 전원 시스템: 디젤 및 가스 발전기 세트에서 응답성이 뛰어나고 안정적이며 신뢰할 수 있는 비상 및 대기 전력을 제공하는 데 사용됩니다.
  • 고속 응용 분야: 마이크로 터빈 및 플라이휠 에너지 저장 시스템과 같은 고속 구동에 적합합니다.
  • 산업 및 군사 장비: 높은 전력 밀도와 최고의 신뢰성이 중요한 특수 목적 및 군사 전력 시스템에 사용됩니다.
맞춤화
영구 자석 발전기 제품 맞춤화 서비스:
  • 브랜드 이름: Greef
  • 모델 번호: GDF
  • 원산지: 중국
  • 인증: CE
  • 최소 주문 수량: 1 세트
  • 가격: 협상 가능
  • 포장 세부 정보: 폼 + 합판 케이스
  • 배송 시간: 25 영업일
  • 지불 조건: T/T
  • 보호 등급: IP54
  • 베어링 브랜드: SKF
  • 고정자 재질: 구리
  • 샤프트 재질: 강철
  • 전류 유형: AC
시스템 솔루션
대체 에너지 발전기
GREEF 회사는 각 고객의 전압, 속도, 전력, 주파수 등의 요구 사항에 따라 맞춤형 발전기를 제공합니다.
최대 120℃ 자석 온도 및 최대 180℃ 권선 온도를 갖는 고효율 영구 자석 발전기 (고부하 작업용) 0 최대 120℃ 자석 온도 및 최대 180℃ 권선 온도를 갖는 고효율 영구 자석 발전기 (고부하 작업용) 1 최대 120℃ 자석 온도 및 최대 180℃ 권선 온도를 갖는 고효율 영구 자석 발전기 (고부하 작업용) 2
포장 및 배송
제품 포장:
당사의 영구 자석 발전기는 고객에게 안전하게 배송될 수 있도록 신중하게 포장됩니다. 각 발전기는 운송 중 손상을 방지하기 위해 충분한 보호 패딩이 있는 튼튼한 판지 상자에 넣습니다. 포장은 거친 취급을 견딜 수 있도록 설계되었으며 목적지에 도달할 때까지 발전기를 안전하게 유지합니다.
배송:
당사는 영구 자석 발전기 제품에 대해 빠르고 안정적인 배송을 제공합니다. 주문은 즉시 처리되며, 당사의 전담 배송 팀은 각 패키지가 적시에 발송되도록 합니다. 귀하의 위치에 따라 표준 및 특급 배송을 포함하여 다양한 배송 옵션을 제공합니다. 귀하의 발전기가 완벽한 상태로 귀하에게 전달될 수 있도록 주의하여 배송될 것입니다.
