12-1140V Rated Voltage 0.5-5000KW Rated Power IP54 Protection Permanent Magnet Generator PMG for High Efficiency Applications

12-1140V Rated Voltage Permanent Magnet Generator

0.5-5000KW Rated Power PMG

IP54 Protection Permanent Magnet Alternator

브랜드 이름:

Greef

인증:

Model Number:

GDF

저희와 연락

인용 을 요청 하십시오

제품 세부 정보

자석 유형:

드페비

베어링 브랜드:

SKF

현재 유형:

냉각방식:

팬 냉각

평가된 볼트아그:

12-1140V

샤프트 재료:

강철

정격 출력:

0.5-5000KW

보호 g:

IP54

지불 및 배송 조건

Minimum Order Quantity

1 Set

가격

negotiable

Packaging Details

Foam+plywooden Case

Delivery Time

25 Working Days

Payment Terms

T/T

12-1140V Rated Voltage 0.5-5000KW Rated Power IP54 Protection Permanent Magnet Generator PMG for High Efficiency Applications

가장 좋은 가격 을 구하라

비디오

0.5-5000KW Rated Power 12-1140V Permanent Magnet Generator with Long-lasting Copper Stator and PMG Design

가장 좋은 가격 을 구하라

비디오

최대 120℃ 자석 온도 및 최대 180℃ 권선 온도를 갖는 고효율 영구 자석 발전기 (고부하 작업용)

가장 좋은 가격 을 구하라

비디오

High Efficiency Permanent Magnet Generator with Cast Iron Shell Copper Stator and NdFeB Magnet

가장 좋은 가격 을 구하라

저희와 연락

지금 연락하세요

제품 설명

12-1140V Rated Voltage Three Phase Stator Material Copper for Performance Advanced Hydro PMG Technology

Offering superior voltage regulation capability with advanced Permanent Magnet Generator (PMG) technology.

Product Overview

A Permanent Magnet Generator (PMG) is an advanced type of electric generator that utilizes high-strength permanent magnets on its rotor to create a powerful magnetic field, instead of relying on traditional electrically-excited windings.

Key Advantages

Higher Efficiency: Reduces energy losses, resulting in superior efficiency, especially under partial loads.
Exceptional Reliability: Brushless structure ensures minimal maintenance and a longer operational lifespan.
Compact & Lightweight: Offers a higher power density, making it ideal for space-constrained applications.
Excellent Performance: Provides superior voltage regulation and faster response.

Technical Specifications

Parameter	Value
Rated power	0.5-5000 kW
Rated rotate speed	20-3000 rpm
Rated voltage	48-1140 Vac
Frequency	60/50 Hz
Number of Poles	24
Generator type	3phase AC Synchronous generator
Magnet type	NdFeB
Winding Method	Y
Magnet temperature level	Max.120℃
Winding temperature level	Max.180℃
Efficiency	>95%
Insulate Grade	H

Performance Ratings

Rated Power	Rated Speed	Rated Voltage	Frequency
0.5KW	20rpm~400rpm	12V~220Vac	10Hz~60Hz
1KW	20rpm~600rpm	12V~220Vac	10Hz~60Hz
2KW	20rpm~1000rpm	12V~400Vac	10Hz~60Hz
3KW	20rpm~1500rpm	48V~690Vac	10Hz~60Hz
5KW	20rpm~1500rpm	48V~690Vac	10Hz~60Hz

Applications

Permanent Magnet Generators (PMGs), renowned for their high efficiency, reliability, and compact design, have emerged as the preferred power solution across various modern industrial sectors.

Wind Power Generation: Integral to modern direct-drive and semi-direct-drive wind turbines
New Energy Vehicles: Primary traction motor or auxiliary generator in electric/hybrid vehicles
Marine and Offshore: Ship shaft generators and primary/auxiliary power systems
Backup Power Systems: Diesel and gas generator sets for emergency power
High-Speed Applications: Microturbines and flywheel energy storage systems
Industrial & Military Equipment: Specialized power systems requiring high reliability

Customization Options

Brand Name: Greef

Model Number: GDF

Certification: CE

Minimum Order Quantity: 1 Set

Delivery Time: 25 Working Days

Bearing brand: SKF

Stator Material: Copper

Packaging & Shipping

Our Permanent Magnet Generator is carefully packaged to ensure safe delivery. Each generator is securely wrapped in bubble wrap and placed in a sturdy cardboard box to prevent any damage during transit.

We offer fast and reliable shipping via reputable carriers. Orders are typically processed within 1-2 business days with tracking provided.
